Lapped Joint Flange
Application:
LAPPED JOINT FLANGE is also called Loose flange or LJ flange,it is used with a stub end, which is welded to the pipe.The advantage of this flange connection is that the flange can be rotated. It is easy to align the bolt holes and easy to install on large diameter pipes.Loose flanges are also suitable for areas where the pipe needs to be removed frequently for cleaning or inspection, or where only the flange and not the pipe need to be rotated when aligning the flange bolt hole.When using the loose flange, the material of the flange stub shall be the same as that of the pipe;And flange material can be different from pipe material, so it is more suitable for conveying corrosive medium of pipe and non-ferrous metal pipe system, in order to achieve as much as possible to save expensive materials (such as stainless steel and non-ferrous metal).
According to the different stubs, the flange can be subdivided into 4 types: butt welding ring with neck loose flange, butt welding ring plate type loose flange, flat welding ring plate type loose flange and flanged ring plate type loose flange.
As the lapped joint flange manufacturers in China, Eathumetals can also supply OEM flanges according to customers’ drawings or designs.
Welcome to contact us for more information.
Specification:
Dimesions of lap joint flanges - ASME B16.5
Dimensions and Weight Chart for ASME/ANSI B16.5 Class 150 Lap Joint Flanges
| DN | NPS | Overall Diameter | Inside Diameter(Min.) | Thickness of Flange(Min.) | Overall Lenght | Lap Radius | Diameter of Hub | Number of Bolts | Diameter of Bolt Holes | Diameter of Bolt Circle |
| A | B | C | D | R | F | H | I | J | ||
| 15 | 1/2 | 90 | 22.9 | 11.2 | 16 | 3 | 30 | 4 | 15.7 | 60.3 |
| 20 | 3/4 | 100 | 28.2 | 12.7 | 16 | 3 | 38 | 4 | 15.7 | 69.9 |
| 25 | 1 | 110 | 34.9 | 14.3 | 17 | 3 | 49 | 4 | 15.7 | 79.4 |
| 32 | 1 1/4 | 115 | 43.7 | 15.9 | 21 | 5 | 59 | 4 | 15.7 | 88.9 |
| 40 | 1 1/2 | 125 | 50 | 17.5 | 22 | 6 | 65 | 4 | 15.7 | 98.4 |
| 50 | 2 | 150 | 62.5 | 19.1 | 25 | 8 | 78 | 4 | 19.1 | 120.7 |
| 65 | 2 1/2 | 180 | 75.4 | 22.3 | 29 | 8 | 90 | 4 | 19.1 | 139.7 |
| 80 | 3 | 190 | 91.4 | 23.9 | 30 | 10 | 108 | 4 | 19.1 | 152.4 |
| 90 | 3 1/2 | 215 | 104.1 | 23.9 | 32 | 10 | 122 | 8 | 19.1 | 177.8 |
| 100 | 4 | 230 | 116.8 | 23.9 | 33 | 11 | 135 | 8 | 19.1 | 190.5 |
| 125 | 5 | 255 | 144.4 | 23.9 | 36 | 11 | 164 | 8 | 22.4 | 215.9 |
| 150 | 6 | 280 | 171.4 | 25.4 | 40 | 13 | 192 | 8 | 22.4 | 241.3 |
| 200 | 8 | 345 | 222.2 | 28.6 | 44 | 13 | 246 | 8 | 22.4 | 298.5 |
| 250 | 10 | 405 | 277.4 | 30.2 | 49 | 13 | 305 | 12 | 25.4 | 362 |
| 300 | 12 | 485 | 328.2 | 31.8 | 56 | 13 | 365 | 12 | 25.4 | 431.8 |
| 350 | 14 | 535 | 360.2 | 35 | 79 | 13 | 400 | 12 | 28.4 | 476.3 |
| 400 | 16 | 595 | 411.2 | 36.6 | 87 | 13 | 457 | 16 | 28.4 | 539.8 |
| 450 | 18 | 635 | 462.3 | 39.7 | 97 | 13 | 505 | 16 | 31.75 | 577.9 |
| 500 | 20 | 700 | 514.4 | 42.9 | 103 | 13 | 559 | 20 | 31.75 | 635 |
| 600 | 24 | 815 | 616 | 47.7 | 111 | 13 | 663 | 20 | 35.1 | 749.3 |
Dimensions and Weight Chart for ASME/ANSI B16.5 Class 300 Lap Joint Flanges
| DN | NPS | Overall Diameter | Inside Diameter(Min.) | Thickness of Flange(Min.) | Overall Lenght | Lap Radius | Diameter of Hub | Number of Bolts | Diameter of Bolt Holes | Diameter of Bolt Circle |
| A | B | C | D | R | F | H | I | J | ||
| 15 | 1/2 | 95 | 22.9 | 14.3 | 22 | 3 | 38 | 4 | 15.7 | 66.7 |
| 20 | 3/4 | 115 | 28.2 | 15.9 | 25 | 3 | 48 | 4 | 19 | 82.6 |
| 25 | 1 | 125 | 34.9 | 17.5 | 27 | 3 | 54 | 4 | 19 | 88.9 |
| 32 | 1 1/4 | 135 | 43.7 | 19.1 | 27 | 5 | 64 | 4 | 19 | 98.4 |
| 40 | 1 1/2 | 155 | 50 | 20.7 | 30 | 6 | 70 | 4 | 22.3 | 114.3 |
| 50 | 2 | 165 | 62.5 | 22.3 | 33 | 8 | 84 | 8 | 19 | 127 |
| 65 | 2 1/2 | 190 | 75.4 | 25.4 | 38 | 8 | 100 | 8 | 22.3 | 149.2 |
| 80 | 3 | 210 | 91.4 | 28.6 | 43 | 10 | 117 | 8 | 22.3 | 168.3 |
| 90 | 3 1/2 | 230 | 104.1 | 30.2 | 44 | 10 | 133 | 8 | 22.3 | 184.2 |
| 100 | 4 | 255 | 116.8 | 31.8 | 48 | 11 | 146 | 8 | 22.3 | 200 |
| 125 | 5 | 280 | 144.4 | 35 | 51 | 11 | 178 | 8 | 22.3 | 235 |
| 150 | 6 | 320 | 171.4 | 36.6 | 52 | 13 | 206 | 12 | 22.3 | 269.9 |
| 200 | 8 | 380 | 222.2 | 41.3 | 62 | 13 | 260 | 12 | 25.4 | 330.2 |
| 250 | 10 | 445 | 277.4 | 47.7 | 95 | 13 | 321 | 16 | 28.4 | 387.4 |
| 300 | 12 | 520 | 328.2 | 50.8 | 102 | 13 | 375 | 16 | 31.7 | 450.8 |
| 350 | 14 | 585 | 360.2 | 54 | 111 | 13 | 425 | 20 | 31.7 | 514.4 |
| 400 | 16 | 650 | 411.2 | 57.2 | 121 | 13 | 483 | 20 | 35 | 571.5 |
| 450 | 18 | 710 | 462.3 | 60.4 | 130 | 13 | 533 | 24 | 35 | 628.6 |
| 500 | 20 | 775 | 514.4 | 63.5 | 140 | 13 | 587 | 24 | 35 | 685.8 |
| 600 | 24 | 915 | 616 | 69.9 | 152 | 13 | 702 | 24 | 41.1 | 812.8 |
Dimensions and Weight Chart for ASME/ANSI B16.5 Class 400 Lap Joint Flanges
| DN | NPS | Overall Diameter | Inside Diameter(Min.) | Thickness of Flange(Min.) | Overall Lenght | Lap Radius | Diameter of Hub | Number of Bolts | Diameter of Bolt Holes | Diameter of Bolt Circle |
| A | B | C | D | R | F | H | I | J | ||
| 15 | 1/2 | 95 | 22.9 | 14.3 | 22 | 3 | 38 | 4 | 15.7 | 66.7 |
| 20 | 3/4 | 115 | 28.2 | 15.9 | 25 | 3 | 48 | 4 | 19 | 82.6 |
| 25 | 1 | 125 | 34.9 | 17.5 | 27 | 3 | 54 | 4 | 19 | 88.9 |
| 32 | 1 1/4 | 135 | 43.7 | 20.7 | 29 | 5 | 64 | 4 | 19 | 98.4 |
| 40 | 1 1/2 | 155 | 50 | 22.3 | 32 | 6 | 70 | 4 | 22.3 | 114.3 |
| 50 | 2 | 165 | 62.5 | 25.4 | 37 | 8 | 84 | 8 | 19 | 127 |
| 65 | 2 1/2 | 190 | 75.4 | 28.6 | 41 | 8 | 100 | 8 | 22.3 | 149.2 |
| 80 | 3 | 210 | 91.4 | 31.8 | 46 | 10 | 117 | 8 | 22.3 | 168.3 |
| 90 | 3 1/2 | 230 | 104.1 | 35 | 49 | 10 | 133 | 8 | 25.4 | 184.2 |
| 100 | 4 | 255 | 116.8 | 35 | 51 | 11 | 146 | 8 | 25.4 | 200 |
| 125 | 5 | 280 | 144.5 | 38.1 | 54 | 11 | 178 | 8 | 25.4 | 235 |
| 150 | 6 | 320 | 171.4 | 41.3 | 57 | 13 | 206 | 12 | 35.4 | 269.9 |
| 200 | 8 | 380 | 222.2 | 47.7 | 68 | 13 | 260 | 12 | 28.4 | 330.2 |
| 250 | 10 | 445 | 277.4 | 54 | 102 | 13 | 321 | 16 | 31.75 | 387.4 |
| 300 | 12 | 520 | 328.2 | 57.2 | 108 | 13 | 375 | 16 | 35.1 | 450.8 |
| 350 | 14 | 585 | 360.2 | 60.4 | 117 | 13 | 425 | 20 | 35.1 | 514.4 |
| 400 | 16 | 650 | 411.2 | 63.5 | 127 | 13 | 483 | 20 | 38.1 | 571.5 |
| 450 | 18 | 710 | 462.3 | 66.7 | 137 | 13 | 533 | 24 | 38.1 | 628.6 |
| 500 | 20 | 775 | 514.4 | 69.9 | 146 | 13 | 587 | 24 | 41.1 | 685.8 |
| 600 | 24 | 915 | 616 | 76.2 | 159 | 13 | 702 | 24 | 47.8 | 812.8 |
Dimensions and Weight Chart for ASME/ANSI B16.5 Class 600 Lap Joint Flanges
| DN | NPS | Overall Diameter | Inside Diameter(Min.) | Thickness of Flange(Min.) | Overall Lenght | Lap Radius | Diameter of Hub | Number of Bolts | Diameter of Bolt Holes | Diameter of Bolt Circle |
| A | B | C | D | R | F | H | I | J | ||
| 15 | 1/2 | 95 | 22.9 | 14.3 | 22 | 3 | 38 | 4 | 15.7 | 66.7 |
| 20 | 3/4 | 115 | 28.2 | 15.9 | 25 | 3 | 48 | 4 | 19 | 82.6 |
| 25 | 1 | 125 | 34.9 | 17.5 | 27 | 3 | 54 | 4 | 19 | 88.9 |
| 32 | 1 1/4 | 135 | 43.7 | 20.7 | 29 | 5 | 64 | 4 | 19 | 98.4 |
| 40 | 1 1/2 | 155 | 50 | 22.3 | 32 | 6 | 70 | 4 | 22.3 | 114.3 |
| 50 | 2 | 165 | 62.5 | 25.4 | 37 | 8 | 84 | 8 | 19 | 127 |
| 65 | 2 1/2 | 190 | 75.4 | 28.6 | 41 | 8 | 100 | 8 | 22.3 | 149.2 |
| 80 | 3 | 210 | 91.4 | 31.8 | 46 | 10 | 117 | 8 | 22.3 | 168.3 |
| 90 | 3 1/2 | 230 | 104.1 | 35 | 49 | 10 | 133 | 8 | 25.4 | 184.2 |
| 100 | 4 | 275 | 116.8 | 38.1 | 54 | 11 | 152 | 8 | 25.4 | 215.9 |
| 125 | 5 | 330 | 144.4 | 44.5 | 60 | 11 | 189 | 8 | 28.4 | 266.7 |
| 150 | 6 | 355 | 171.4 | 47.7 | 67 | 13 | 222 | 12 | 28.4 | 292.1 |
| 200 | 8 | 420 | 222.2 | 55.6 | 76 | 13 | 273 | 12 | 31.75 | 349.2 |
| 250 | 10 | 510 | 277.4 | 63.5 | 111 | 13 | 343 | 16 | 35.1 | 431.8 |
| 300 | 12 | 560 | 328.2 | 66.7 | 117 | 13 | 400 | 20 | 35.1 | 489 |
| 350 | 14 | 605 | 360.2 | 69.9 | 127 | 13 | 432 | 20 | 38.1 | 527 |
| 400 | 16 | 685 | 411.2 | 76.2 | 140 | 13 | 495 | 20 | 41.1 | 603.2 |
| 450 | 18 | 745 | 462.3 | 82.6 | 152 | 13 | 546 | 20 | 44.5 | 654 |
| 500 | 20 | 815 | 514.4 | 88.9 | 165 | 13 | 610 | 24 | 44.5 | 723.9 |
| 600 | 24 | 940 | 616 | 101.6 | 184 | 13 | 718 | 24 | 50.8 | 838.2 |
Dimensions and Weight Chart for ASME/ANSI B16.5 Class 900 Lap Joint Flanges
| DN | NPS | Overall Diameter | Inside Diameter(Min.) | Thickness of Flange(Min.) | Overall Lenght | Lap Radius | Diameter of Hub | Number of Bolts | Diameter of Bolt Holes | Diameter of Bolt Circle |
| A | B | C | D | R | F | H | I | J | ||
| 15 | 1/2 | 120 | 22.9 | 22.3 | 32 | 3 | 38 | 4 | 22.3 | 82.6 |
| 20 | 3/4 | 130 | 28.2 | 25.4 | 35 | 3 | 44 | 4 | 22.3 | 88.9 |
| 25 | 1 | 150 | 34.9 | 28.6 | 41 | 3 | 52 | 4 | 25.4 | 101.6 |
| 32 | 1 1/4 | 160 | 43.7 | 28.6 | 41 | 5 | 64 | 4 | 25.4 | 111.1 |
| 40 | 1 1/2 | 180 | 50 | 31.8 | 44 | 6 | 70 | 4 | 28.4 | 123.8 |
| 50 | 2 | 215 | 62.5 | 38.1 | 57 | 8 | 105 | 8 | 25.4 | 165.1 |
| 65 | 2 1/2 | 245 | 75.4 | 41.3 | 64 | 8 | 124 | 8 | 28.4 | 190.5 |
| 80 | 3 | 240 | 91.4 | 38.1 | 54 | 10 | 127 | 8 | 25.4 | 190.5 |
| 100 | 4 | 290 | 116.8 | 44.5 | 70 | 11 | 159 | 8 | 31.7 | 235 |
| 125 | 5 | 350 | 144.4 | 50.8 | 79 | 11 | 190 | 8 | 35 | 279.4 |
| 150 | 6 | 380 | 171.4 | 55.6 | 86 | 13 | 235 | 12 | 31.7 | 317.5 |
| 200 | 8 | 470 | 222.2 | 63.5 | 114 | 13 | 298 | 12 | 38.1 | 393.7 |
| 250 | 10 | 545 | 277.4 | 69.9 | 127 | 13 | 368 | 16 | 38.1 | 469.9 |
| 300 | 12 | 610 | 328.2 | 79.4 | 143 | 13 | 419 | 20 | 38.1 | 533.4 |
| 350 | 14 | 640 | 360.2 | 85.8 | 156 | 13 | 451 | 20 | 41.1 | 558.8 |
| 400 | 16 | 705 | 411.2 | 88.9 | 165 | 13 | 508 | 20 | 44.4 | 616 |
| 450 | 18 | 785 | 462.3 | 101.6 | 190 | 13 | 565 | 20 | 50.8 | 685.8 |
| 500 | 20 | 855 | 514.4 | 108 | 210 | 13 | 622 | 20 | 53.8 | 749.3 |
| 600 | 24 | 1040 | 616 | 139.7 | 267 | 13 | 749 | 20 | 66.55 | 901.7 |
Dimensions and Weight Chart for ASME/ANSI B16.5 Class 1500 Lap Joint Flanges
| DN | NPS | Overall Diameter | Inside Diameter(Min.) | Thickness of Flange(Min.) | Overall Lenght | Lap Radius | Diameter of Hub | Number of Bolts | Diameter of Bolt Holes | Diameter of Bolt Circle |
| A | B | C | D | R | F | H | I | J | ||
| 15 | 1/2 | 120 | 22.9 | 22.3 | 32 | 3 | 38 | 4 | 22.3 | 82.6 |
| 20 | 3/4 | 130 | 28.2 | 25.4 | 35 | 3 | 44 | 4 | 22.3 | 88.9 |
| 25 | 1 | 150 | 34.9 | 28.6 | 41 | 3 | 52 | 4 | 25.4 | 101.6 |
| 32 | 1 1/4 | 160 | 43.7 | 28.6 | 41 | 5 | 64 | 4 | 25.4 | 111.1 |
| 40 | 1 1/2 | 180 | 50 | 31.8 | 44 | 6 | 70 | 4 | 28.4 | 123.8 |
| 50 | 2 | 215 | 62.5 | 38.1 | 57 | 8 | 105 | 8 | 25.4 | 165.1 |
| 65 | 2 1/2 | 245 | 75.4 | 41.3 | 64 | 8 | 124 | 8 | 28.4 | 190.5 |
| 80 | 3 | 265 | 91.4 | 47.7 | 73 | 10 | 133 | 8 | 25.4 | 190.5 |
| 100 | 4 | 310 | 116.8 | 54 | 90 | 11 | 162 | 8 | 31.7 | 235 |
| 125 | 5 | 375 | 144.4 | 73.1 | 105 | 11 | 197 | 8 | 35 | 279.4 |
| 150 | 6 | 395 | 171.4 | 82.6 | 119 | 13 | 229 | 12 | 31.7 | 317.5 |
| 200 | 8 | 485 | 222.2 | 92.1 | 143 | 13 | 292 | 12 | 38.1 | 393.7 |
| 250 | 10 | 585 | 277.4 | 108 | 178 | 13 | 368 | 16 | 38.1 | 469.9 |
| 300 | 12 | 675 | 328.2 | 123.9 | 219 | 13 | 451 | 20 | 38.1 | 533.4 |
| 350 | 14 | 750 | 360.2 | 133.4 | 241 | 13 | 495 | 20 | 41.1 | 558.8 |
| 400 | 16 | 825 | 411.2 | 146.1 | 260 | 13 | 552 | 20 | 44.4 | 616 |
| 450 | 18 | 915 | 462.3 | 162 | 276 | 13 | 597 | 20 | 50.8 | 685.8 |
| 500 | 20 | 985 | 514.4 | 177.8 | 292 | 13 | 641 | 20 | 53.8 | 749.3 |
| 600 | 24 | 1170 | 616 | 203.2 | 330 | 13 | 762 | 20 | 66.55 | 901.7 |
Dimensions and Weight Chart for ASME/ANSI B16.5 Class 2500 Lap Joint Flanges
| DN | NPS | Overall Diameter | Inside Diameter(Min.) | Thickness of Flange(Min.) | Overall Lenght | Lap Radius | Diameter of Hub | Number of Bolts | Diameter of Bolt Holes | Diameter of Bolt Circle |
| A | B | C | D | R | F | H | I | J | ||
| 15 | 1/2 | 135 | 22.9 | 30.2 | 40 | 3 | 43 | 4 | 22.3 | 88.9 |
| 20 | 3/4 | 140 | 28.2 | 31.8 | 43 | 3 | 51 | 4 | 22.3 | 95.2 |
| 25 | 1 | 160 | 34.9 | 35 | 48 | 3 | 57 | 4 | 25.4 | 108 |
| 32 | 1 1/4 | 185 | 43.7 | 38.1 | 52 | 5 | 73 | 4 | 28.4 | 130.2 |
| 40 | 1 1/2 | 205 | 50 | 44.5 | 60 | 6 | 79 | 4 | 31.75 | 146 |
| 50 | 2 | 235 | 62.5 | 50.9 | 70 | 8 | 95 | 8 | 28.4 | 171.4 |
| 65 | 2 1/2 | 265 | 75.4 | 57.2 | 79 | 8 | 114 | 8 | 31.75 | 196.8 |
| 80 | 3 | 305 | 91.4 | 66.7 | 92 | 10 | 133 | 8 | 35.1 | 228.6 |
| 100 | 4 | 355 | 116.8 | 76.2 | 108 | 11 | 165 | 8 | 41.1 | 273 |
| 125 | 5 | 420 | 144.4 | 92.1 | 130 | 11 | 203 | 8 | 47.8 | 323.8 |
| 150 | 6 | 485 | 171.4 | 108 | 152 | 13 | 235 | 8 | 53.8 | 368.3 |
| 200 | 8 | 550 | 222.2 | 127 | 178 | 13 | 305 | 12 | 53.8 | 438.2 |
| 250 | 10 | 675 | 277.4 | 165.1 | 229 | 13 | 375 | 12 | 66.55 | 539.8 |
| 300 | 12 | 760 | 328.2 | 184.2 | 254 | 13 | 441 | 12 | 73.15 | 619.1 |
Product Details
1. Size: 1/2"-60"(DN10-DN1500)
2. Types: Slip-On flange, Welding Neck flange, Blind flange, Socket Welding flange, Threaded flange, Lap Joint flange, Plate flange, Long Welding Neck and flat flange etc;
3. Material:
Carbon steel: ASTM A105/SA105N; ASTM A350 LF1; LF2; CL1/CL2, CT20;16MN;RST37.2;S235JR;P245GH;P250GH;P250GHM; C22.8;Q235;15CrMo
Stainless steel: ASTM A182, SS303; SS304/304L; SS316/316L; F321; F347; 316Ti; A182F317/317L; SS400;SF440
Alloy Steel:ASTM A182 A182 F12,F11,F22,F5,F9,F91,F51,F53,F55,F60,F44,F304H,F316H,F317H,F321H,F347H,INCONEL 600,625,825,etc.
4. Wall Thickness: Sch5, Sch10, Sch20 , Sch30, STD, Sch40, XS,Sch80, Sch100, Sch120, Sch140, XXS, Sch160;
5. Connection Type: Raised Face, Flat Face, Ring Type Joint, Lap-Joint Face, Large Male-Female, Small Male-Female, Large Tongue, Groove, Small-Tongue, Groove, etc
6. Pressure Rating:
ANSI B16.5: Class 150 Flanges-Class 2500 Flanges；
DIN: 6Bar 10Bar 16Bar 25Bar 40Bar 63Bar
JIS: 5K Flanges-30K Flanges
EN1092-1: 6Bar 10Bar 16Bar 25Bar 40Bar 63Bar 100Bar
7. Surface treatment: Anti-rust oil, black / yellow / transparent / electric galvanized / hot galvanized.
8. Sealing Surface: FF, RF, MFM, TG, FF
9. Heat Treatment: Normalizing, Annealing, Quenching Tempering.
10. Standard:
(1) ANSI B16.5, A105 150LB / 300LB / 600LB / 900LB / 1500LB / 2500LB
(2) DIN 2573 PN6 / DIN 2576 PN10 / DIN2502 PN16 / DIN2503 P25-40 / DIN2566 PN16 / DIN2631-2635 RST37.2 OR C22.8
(3) JIS SS400 OR SF440 5K / 10K / 16K / 20K / 30K
(4) UNI 2276 / 2277 / 2278 / 6084 / 6089 / 6090 / 2544 / 2282 / 6091-6093
(5) EN1092 PN6 / PN10 / PN16 / PN25 / PN40 / TYPE1 TYPE2 TYPE 5 TYPE 12 TYPE 13
(6) BS4504 SANI1123 1000/3, 1600/3, 2500/3, T/D, T/E, T/F carbon steel flange
(7) AS2129 TABLE D / TABLE H / TABLE E carbon steel flange
(8) GOST 12820-80 / 12821-80 carbon steel flange
11. Tolerance: according to the standard.
12. Certification: ISO9001:2000 , API, CE
13. Package: Plywood pallet or case.
14. Delivery time: At the earliest ,within the period required by customer.
15. Payment term: T/T or L/C
16. Sample: available
inquire now
If you have any questions or needs about the product, please fill in the following form and we will contact you as soon as possible.
